Buick Regal 2018-2025 Service Manual / Transmission / Power Transfer Unit/Transfer Case - AAM / Special Tools and Equipment

Buick Regal: Special Tools and Equipment

SPECIAL TOOLS

DT - 113 - 2 - A

J - 03289-20

KM - 113-2-A

Holding Fixture

Power Transfer Unit/Transfer Case

DT-305-1

J-42176

KM-305-1

Driver Handle

Power Transfer Unit/Transfer Case

DT - 26941

J - 26941

Bushing and Bearing Remover - 3 - 4 in.

Power Transfer Unit/Transfer Case

DT - 29369 - 1

J - 29369 - 1

Bushing and Bearing Remover

Power Transfer Unit/Transfer Case

DT - 36842

J - 36842

Transaxle Holding Fixture

Power Transfer Unit/Transfer Case

DT - 36850

J - 36850

Transjel Lubricant

Power Transfer Unit/Transfer Case

DT-44380

J-44380

Differential Bearing Puller

Power Transfer Unit/Transfer Case

DT-45124

J-45124

Removal Bridge

Power Transfer Unit/Transfer Case

DT-45124 - 9

J-45124 - 9

Puller Leg

Power Transfer Unit/Transfer Case

DT - 51466

Seal Installer

Power Transfer Unit/Transfer Case

DT - 51467 - A

Seal Installer

Power Transfer Unit/Transfer Case

GE- 28431 - 6

J - 28431 - 6

Florescent Oil Dye - 6 1 oz.

Power Transfer Unit/Transfer Case

GE-42220

J-42220

High-Intensity Black Light Kit

Power Transfer Unit/Transfer Case
